Description
Technical Data Features
Total introduced power: max 10.4kW – min 3.5kW
Nominal heat output: max 9kW – min 3.2kW
Efficiency: Pmax 87% – Pmin 90%
CO emission at 13% O2: Pmax 0,012% – Pmin 0,020%
Pellet consumption: max 2.2kg/h – min 0.7kg/h 5
Reservoir capacity: 13.5kg
Heatable room volume: 140 – 200 mc
Minimum clearance: side: 25cm – back: 10cm – front side: 100 cm
Dimension: W 850 x D252 x H 1024 mm
Weight: 98.3 kg
Cast iron combustion chamber
Stainless steel brazier
Canalized stove, double ventilation:Basic; Optional
Complies with: EN14785 – BImSchV II – 15a B-VG – LRV/VKF
Sliding drawer for ash removal
Flue outlet: Rear
Remote control: Optional
